Description
Key features
High-grade thin wall PVC sleeving ideal for insulating wire in areas where space is at a premium
Supplied in continuous 100m coils
Some sizes are available supplied on reels, please contact us for more information
Specification
Material: PVC
Colours available: Black, blue, brown, green, grey, red, white, yellow
Operating temperature: -20°C to +70°C
Insulation resistance: 1010 Ohm/cm
Dielectric strength: 20 kV/mm
Elongation at break: 220%
Tensile strength: 15MPa
Hardness: BSS20-30
Flammability: Self Extinguishing in 30 seconds
Approvals: BS 2848/3/85T, RoHS compliant
